-10%
SPRO 8MP Colour Night 2.0 Smart Dual Illumination Turret Network Camera with Built-in Mic DHIPD80/28LRW-M
Original price was: £158.99.£142.99Current price is: £142.99. inc VAT
KEY FEATURES:
- 8 Megapixel (3840×2160) @ 20fps
- 2.8mm Fixed Lens
- AI-PRO Intelligent human & vehicle target classification alerts
- Micro SD slot (Up to 256gb)
- Supports Smart H.264+/H.265+ compression
- Up to 30m IR & LED distance
- Microphone built-in (audio over CAT5e cable)
- 120dB WDR
- IP67 waterproof
- DC 12V/POE
The new 8MP (4K) POE Colour Night 2.0 Turret camera comes in at double the resolution, while retaining all features of the first generation model. The new model packs a punch with built-in infrared technology, allowing the camera to act like a security light.
With the aid of its supplement 30m white light, the camera can record colourful videos both day and night however the built in infrared technology allows the camera to stay in black and white mode and have the white light activate on motion. The built in microphone allows capture of audio for evidential purposes and the IP67 weatherproof rating makes the camera suitable for both indoor and outdoor use.
The new model offers 3 adjustable light settings that can be configured from the SPRO mobile app. If you have more than one camera, each cameras dual illumination setting can be adjusted independently in either of the following lighting modes:
- Smart Illumination Mode – in this mode, there is one setting;
Automatic – in this intelligent mode, the camera will go into black/white infrared mode at night and the while light will only illuminate on detection of motion. - Warm Light Mode – in this mode, there are 3 selectable settings;
Enable the white will operate 24/7, both day and night
Automatic will act just like the first generation model, where the white light will automatically illuminate in low light conditions and will turn off automatically at sunrise or until there is adequate ambient light
Close will disable the white light from coming on however this also prevents IR mode from kicking in - IR mode – in this mode, there are 3 selectable settings;
Enable the infrared mode will operate 24/7 and the video will appear black and white both day and night - Automatic in this mode, the camera will go into infrared mode just like a conventional CCTV camera and the video will appear black and white at night
- Close will disable the infrared from coming on however this also prevents white light mode from kicking in
| Model Number | DHIPD80/28LRW-M |
| Image Sensor | 1/2.7″ CMOS |
| Max. Resolution | 3280 (H)x2160(V) |
| ROM | 128 MB |
| RAM | 256MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s-1/100.000 s |
| Min. Illumination | 0.008 lux@F1.6 (Colour, 30 IRE) 0.0008 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | >56dB |
| Illumination Distance | 30 m (98.43 ft) (IR); 30 m (98.43 ft) (Warm light) |
| Illuminator On/Off control | Auto/Manual |
| Illuminator Number | 1 (IR LED); 1(Warm light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8mm |
| Max. Aperture | F1.6 |
| Field of View | 2.8 mm: H: 111°; V: 58°; D: 132° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 1.5 m (4.92 ft) |
| DORI Distance | Detect: 84.8m
Observe: 33.9m Recognize: 17.0m Identify: 8.5m |
| Intelligence | |
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream: 3840 × 2160 @(1–20 fps )/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 × 1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps |
| Day/Night | Auto(ICR)/Colour/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto; Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 Areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Defog | Yes |
| Privacy Masking | 4 areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network | |
| Network Port | RJ-45 (10/100/1000 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| User/Host | 20 (Total bandwidth:48 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser | IE: Chrome Firefox |
| Management Software | DMSS |
| Mobile Client | iOS; Android |
| Cyber Security | Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification |
| Power | |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power consumption | Basic: 2.6 W (12 VDC); 3.3 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + warm light intensity + IVS): 5 W (12 VDC); 5.9 W (PoE) |
| Environment | |
| Operating Temperature | –40 °C to +55 °C (–40 °F to +131 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Protection | IP67 |
| Structure | |
| Casing | Metal |
| Product Dimensions | 89.2 mm × Φ105.0 mm |
| Net Weight | 0.365 kg |
| Gross Weight | 0.527 kg |
| Title | Type | Size | |
|---|---|---|---|
|
DHIPD8028LRW-M | application/pdf | 404 KB |
| Brand | SPRO |
|---|---|
| Resolution | 8 MegaPixel |
| Technology | IP |
| Features | 24/7 Colour, Microphone Built-In, PoE, Smart Dual Illuminaton |
